• Intel Core 2 multi-core and upcoming 45nm processors
GA-G31M-S2C supports Intel latest high performance CPU delivers the most energy-efficient performance available today. Based on Intel's Micro Architecture, the Intel multi-core processors with 4 cores and two shared L2 caches provide the best capability-per-watt solutions and are an ideal choice for multi-media enthusiasts and intensive multi-tasking environments. This cutting-edge processor offers significant performance boosts and provides an overall more energy efficient platform
• Solid Capacitor for CPU VRM
Stable system operation depends upon the quality of CPU VRM (voltage regulator module). GIGABYTE adopts Conductive Polymer Aluminum Solid Capacitors for CPU VRM to ensure a longer lifespan for systems in daily operation and boost system stability under extreme conditions. CPU VRM with Solid Capacitors featuring better electronic conductivity, excellent heat resistance enhances system durability even operating in high temperature environment.
• PCI Express Interface
Revolutionary PCI Express interface provides scalable bandwidth for multi-purpose usage. PCI-E x16 interface delivers the utmost graphics experience; PCI-E x1interface delivers twice the bandwidth of PCI interface up to 250MB/s for new generation I/O peripheral devices.
• Dual Channel DDR2 1066 by O.C
Get a jump in memory performance with the advanced technology of DDR2 1066 memory architecture by overclocking, which delivers superior performance for the most demanding applications.
• Intel GMA 3100
Intel Graphics Media Accelerator 3100 support Microsoft DirectX 9.0 and Windows Vista Aero experience. The 3D enhancement of GMA 3100 highly improves the realism and graphics performance..
• SATA 3Gb/s storage interface
The SATA specification doubles bus bandwidth from 1.5Gb/s to 3Gb/s. Native Command Queuing is a new specification that enables out-of-order execution of commands for efficient retrieval of data. Hot Plug support allows users to insert and remove hard disk drives without shutting off power to the system.
• Ethernet 10/100Mbps Network Connection
The onboard 10/100 Mbps Ethernet LAN connection offers a cost-saving and reliable solution for value-minded users requiring straightforward network connectivity.
• Smart
The Smart featured motherboards of GIGABYTE S-series provide GIGABYTE proprietary innovative software such as Download Center, @BIOS, Q-Flash, Xpress Install, Boot menu, and Smart Fan. BIOS and driver management now becomes much easier and user friendly through GIGABYTE Smart features!...more
• Safe
Safe is the key feature of GIGABYTE S-series motherboards with the following elements: Excellent hardware design reinforced BIOS protection through GIGABYTE Virtual Dual BIOS Technology and GIGABYTE BIOS Setting Recovery Technology. Unique system software such as Xpress Recovery 2, PC Health Monitor, HDD S.M.A.R.T., and C.O.M. further strengthen the stability and reliability of your PC!...more
• RoHS compliant
As a member of the global community to look after the environment, Gigabyte complies with the European Union's Restriction of use of certain Hazardous Substances (RoHS) directive which limits the use of lead, mercury, cadmium and other hazardous substances in electronic products.. From components and material selection to production processes, make up of accessories, packaging/color boxes etc; GIGABYTE has carefully examined and designed this product to be 100% RoHS compliant. GIGABYTE will continue to develop RoHS compliant PC components and commit valuable resources to promoting and advancing RoHS directive goals and objectives
|
| tip procesor | • INTEL Celeron Dual Core E1400
▫ Frequence : 2000 MHz
▫ Socket : S775
▫ FSB : 800 MHz
▫ Cache Level 2 : 512 KB
▫ Technology : 65 nm
▫ Operation : 64 biti
|
| tehnologii multimedia | ▫ High Definition Audio
▫ Realtek ALC662 codec
▫ 2/4/5.1-channel
▫ Support for S/PDIF Out
▫ Support for CD In
|
| placa de baza | • Motherboard GIGABYTE GA-G31M-S2C
Chipset
▫ North Bridge: Intel® G31 Express Chipset
▫ South Bridge: Intel® ICH7
FSB
▫ 1600(O.C.)/1333/1066/800MHz
CPU support for:
▫ Intel® Core™ 2 Extreme processor
▫ Intel® Core™ 2 Quad processor
▫ Intel® Pentium® Dual-Core processor
▫ Intel® Celeron® processor in the LGA 775 package
Storage Interface
▫ 1 x IDE connector supporting ATA-100/66/33 and up to 2 IDE devices
▫ 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
Expansion Slots
▫ 1 x PCI Express x 16 slot
▫ 1 x PCI Express x 1 slot
▫ 2 x PCI slots
USB - integrated in the South Bridge
▫ Up to 8 USB 2.0 or 1.1 ports (4 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors
▫ 1 x 24-pin ATX main power connector
▫ 1 x 4-pin ATX 12V power connector
▫ 1 x floppy disk drive connector
▫ 1 x IDE connector
▫ 4 x SATA 3Gb/s connectors
▫ 1 x CPU fan header
▫ 1 x system fan header
▫ 1 x front panel header
▫ 1 x front panel audio header
▫ 1 x CD In connector
▫ 1 x S/PDIF Out header
▫ 2 x USB 2.0/1.1 headers
▫ 1 x chassis intrusion header
▫ 1 x power LED header
I/O Controller
▫ iTE IT8718 chip
H/W Monitoring
▫ System voltage detection
▫ CPU temperature detection
▫ CPU/System fan speed detection
▫ CPU overheating warning
▫ CPU/System fan fail warning
▫ CPU fan speed control
BIOS
▫ 1 x 4 Mbit flash
▫ Use of licensed AWARD BIOS
▫ PnP 1.0a, DMI 2.0, SM BIOS 2.3, ACPI 1.0b
Unique Features:
▫ Support for @BIOS
▫ Support for Download Center
▫ Support for Q-Flash
▫ Support for EasyTune
▫ Support for Xpress Install
▫ Support for Xpress Recovery2
▫ Support for Virtual Dual BIOS
Form Factor:
▫ Micro ATX form factor; 24.4cm x 19.3cm
Remark
▫ Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors website or 3rd party website.
▫ Due to most hardware and software vendors no longer offer support for Win9X, ME. If some vendors still has Win9X, ME drivers available, we will publish on website.
|
| memorie standard | • Memory RAM 1GB
▫ Dual channel architecture;
▫ DDR II, PC5300, 667 MHz, Kingston ValueRAM |
| capacitate maxima memorie | 4 GB |
| HDD intern | • SEAGATE hard disk drive 160GB
▫ Serial ATA 2
▫ 8MB buffer
▫ 7200 rpm |
| adaptor video | Onboard graphics integrated in the North Bridge
|
| model ecran (monitor) | • Monitor LG 19 inch 1942S-BF |
| diagonala ecran/vizibil (cm.) | 19 inch (48cm) |
| contrast imagine | 700:1 |
| tip tehnologie ecran | LCD |
| tehnologie imagine | DFC - Technology for Superb Viewing Experience |
| tip ecran | 4 x 3 |
| viteza de raspuns | 5ms (Typical) |
| rezolutie ecran | 1280 x 1024 |
| marime punct | 0.282 x 0.282 |
| unghi vizibilitate h/v | H : 170°/V : 170°(CR≥5) |
| frecventa orizontala | 30~83Khz |
| frecventa verticala | 56~75Hz |
| numar culori afisabile | 16.700.000 |
| stralucire | 300cd/㎡ |
| FDD | • SONY floppy disk drive 3.5" |
| cd-rom/dvd | • LG DVD±RW - GH22NS40
SATA interface
Super multi 22x
|
| interfata retea | • Ethernet LAN 10/100 Mbps |
| modem | optional |
| porturi externe i/o | ▫ 1 x PS/2 keyboard port
▫ 1 x PS/2 mouse port
▫ 1 x parallel port
▫ 1 x serial port
▫ 1 x D-Sub port
▫ 4 x USB 2.0/1.1 ports
▫ 1 x RJ-45 port
▫ 3 x audio jacks (Line In/Line Out/Microphone)
|
| mouse/dispozitive de indicare | • LG Mouse optic scroll 3D 510
▫ PS/2 |
| tastatura | • LG Keyboard ST220
▫ PS/2 |
| format standard | Small form factor |
| tip carcasa | • Middletower case ATX MF-483
▫ Power: 450W
▫ CD/DVD: 4 bays
▫ HDD slot: 1+1
▫ FDD slot: 1
▫ Frontal Audio port: 1
▫ Frontal microfon: 1
▫ Frontal USB: 1
▫ Intel TAC air |
| compatibilitate cu sisteme de operare | - Microsoft Windows Vista
- Microsoft Windows XP Professional
|
| reteaua de alimentare | 100/240 Va.c. ± 10%, 50/60 Hz ± 3% |
| energy star | yes |
| consum | ▫ Processor case: max. 390W
▫ Display: max. 40W |
| dimensiuni (w x d x h) | ▫ Processor case: 450 x 192 x 445mm
▫ Display: 465 x 70 x 418mm |
| greutate | ▫ Processor case: 5,4Kg
▫ Display: 4,7Kg |
| garantie | 36 luni |
